Details
| Operating System | Embedded LINUX |
| Display | |
| interface | 1. HDMI (2K), 1. VGA |
| Resolution | 1920x1080; 16:9 |
| multi screen display | 1, 4, 8, 9, 16 |
| multi mode input | analog: 4*5M-N 15fps (5 in 1)；4*1080P |
| hybrid: 2*1080P(analog)+2*1080P(network)/4*1080N(analog)+4*960P(network) | |
| network：4*5MP;16*1080P,9*1080P;16*960P | |
| OSD | camera title, time, video loss, camera lock, motion detection, recording |
| Motion detection and alarm | |
| Trigger Events | Recording, PTZ, Tour, Alarm out, Video Push, Email, FTP |
| Motion Detection | MD Zones: 192(16×12), Video Loss & Camera Blank |
| Abnormmality | No Storage/ Storage device error/ Storage No space |
| Alarm Input | N/A |
| Alarm Output | N/A |
| Playback & Backup | |
| Playback | 1/2/4 channels (according to selected mode) |
| Search Mode | Time/Date, Alarm, MD & Exact search (accurate to second) |
| Playback Function | Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom |
| Backup Mode | USB Device/Network |
| Network | |
| Interface | 1 RJ-45 ports (10/100 Mbps) |
| Ethernet Port | 1 independent 10/100 Mbps Ethernet ports |
| Network Function | HTTP, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE, DDNS, FTP, Alarm Server, IP Search(Support Dahua IP camera, DVR, NVS etc.) |
| wireless | 3G, Wifi |
| Max. User Access | 60 users |
| Smart Phone App | "XMEYE" on both platforms (iOS, Android) |
| Computer System Support | Windows 2000, XP, Vista, 7, 8 / Mac OS x 10.6/10.7 |
| CMS Program | XMEYE |
| Free DDNS (P2P) | P2P Function via iCloud server (http://www.xmeye.net) |
| Storage | |
| Internal HDD | 1 SATA II ports (support 8TB) |
| HDD Mode | read / write, read only, redundant |
| Auxiliary Interface | |
| USB | 2 USB 2.0 ports |
| RS485 | 1 port, support all kind of PTZ protocal |
| Video & Audio | |
| Camera Input | 4 channel BNC |
| Two-way Talk | 1 channel Input, 1 channel Output, RCA, full Duplex enabled |
| Audio compression | G.711A |
| Recording | |
| Video compression | H.265X |
| Resolution | 5M-N, 1080P, 1080N etc. |
| Record Rate | 384 Mbps |
| Bit Rate | 16 kbit/s to 40 Mbit/s |
| Record Mode | Manual, Schedule, (Regular,Continuous), MD(Video detection: Alarm detection, Video loss), Alarm, Stop |
| Record Interval | 1 to 120 min (default: 60 min), Pre-record: 1 to 30 sec, Post-record: 10 to 300 sec |
| General | |
| Power Supply | 12V |
| Power Consumption | <15 W (Without HDD) |
| WorkingEnvironment | temperature: 0°C to +55°C; Humidity: 10% to 90%RH; pressure 86 to 106 kpa |
| Dimension(W×D×H) | 345 mm x 285 mm x 75 mm |
| Weight | Around 1.05 kg without HDD |
| Certification | CE, FCC, UL |
