Details
| Video & Audio Input | |
| Analog video input | 16PCS BNC Port(Level: 1.0Vp-p, impedance : 75Ω) |
| Audio input | 02PCS RCA Port(Level : 2.0Vp-p, impedance : 1kΩ) |
| Video & audio output | |
| HDMI output | 800x600，1024x768，1280x1024，1440x900，720P，1080P |
| CVBS output | NO |
| VGA output | 800x600，1024x768，1280x1024，1440x900，720P，1080P |
| Audio output | 1PCS RCA Port( line level , impedance : 1kΩ) |
| Video & audio code and decode parameters | |
| Multi-mode switch | AHD: 16CH*1080P；08CH*1080P ; 16CH*1080N |
| AHD+IP: 8CH*1080P(analog) + 8CH*1080P(network); | |
| IP: 8CH*1080P + 8CH*960P；8CH*3M；4CH*5M； | |
| Video compress standard | H.264 |
| Playback Quality | 1080P/720P/960H |
| Motion Detection | Each screen canbe set to 192 (16 *12) detection areas;multi-level sensitivitycan be set (Limited localchannel) |
| Encode Ability | 16CH*1080P @15fps |
| Decode Ability | 16CH*1080P @12fps |
| Audio compress standard | G.711A |
| Record & Playback | |
| Record mode | manual>alarm>motion detection>timing |
| LocalPlayback | 4ch(local input mode) |
| Searchmode | Search bytime, calendar, event, channel |
| Synchronously playback channels | 1/4/8/9/16CH （It is defined with the mode switch） |
| Storage & Backup | |
| Space Occupation | 1080P 20G~30G/day*channel; 720P 12 ~20G/day*channel; 960H 12G/ day*channel; audio：691.2M/day*channel |
| Video storage | HDD, Network |
| Backup mode | Network, USB Harddisk, USB burner, SATA Burner |
| Hard driver | |
| Mode | 2*SATA |
| HDD capacity | each port support max 4TB HDD |
| External port | |
| Internet port | 1PCS RJ45 10M / 100M adaptive Ethernet port |
| Serial port | 1PCS RS485 Port; Support multiple PTZ protocols |
| USB port | 2*USB 2.0 |
| Alarm input | NO |
| Alarm output | NO |
| System | |
| Operating System | embedded Linux |
| System resources | Simultaneously multi-channel real-time recording, playback, network |
| operation,USBbackup | |
| Interface | |
| Operator Interface | Support 16-bit true color graohical menu interface and mouse operation |
| Preview | 1/4/8/9/16 |
| Other | |
| Power supply | DC12V 4A |
| Power consumtion(without HDD) | ≤15W |
| Work temperature | 0℃--＋55℃ |
| Work humidity | 10％--90％ |
| Box Size ( W*L*H (cm) ) | 35*33*8.5cm (Tolerance +3cm) |
