Details
| Video & Audio input | |
| Analog video input | 16PCS BNC Port(Level: 1.0Vp-p, impedance : 75Ω) |
| Audio input | 16PCS RCA Port(Level : 2.0Vp-p, impedance : 1kΩ) |
| Video & Audio Output | |
| HDMI output | 800x600，1024x768，1280x1024，1440x900，720P，1080P |
| CVBS output | NO |
| VGA output | 800x600，1024x768，1280x1024，1440x900，720P，1080P |
| Audio output | 1PCS RCA Port( line level , impedance : 1kΩ) |
| Video & Audio Code and Decode Parameters | |
| Multi-mode switch | AHD: 16CH*720P(compatible with 960H analog) |
| AHD+IP: 8CH*720P+8CH*IPC1080P; 16CH*720P+4CH*IPC1080P | |
| IP: 16CH*1080P; 9CH*3MP; 4CH*5MP | |
| Video compress standard | H.264 |
| Vdieo code resolution | CIF/D1/960H/720P/960P/1080P/3M/5M |
| Playback resolution | 720P 16CH 240/288 FPS+1080P 100/120FPS ; 720P 8CH 200/240FPS ;（It is defined with the mode switch） |
| Video frame rate | NTSC：1~30FPS/S；PAL：1~25FPS/S |
| Video code rate | 256kps/384Kbps/512Kbps/640kbps/768Kbps/1M/1.5M/2M/2.5M/3M/4M/5M/6M/8M |
| Code stream mode | combine streams/ video stream |
| Audio compress standard | ADPCM |
| Audio code rate | 16kpbs |
| Dual-stream | YES |
| Synchronously playback channels | 1/4/9/16CH |
| Hard Driver | |
| Mode | 4*SATA |
| HDD capacity | each port support max 4TB HDD |
| External Port | |
| Voice Intercom | 1PCS RCA Port(Level : 2.0Vp-p, impedance : 1kΩ) |
| Internet port | 1PCS RJ45 10M / 100M adaptive Ethernet port |
| Serial port | 1PCS RS485 Port |
| ;1PCS RS232 Port | |
| USB port | 2*USB2.0 |
| Alarm input | 16 |
| Alarm output | 2 |
| Other | |
| Power supply | DC12V |
| Power consumtion(without HDD) | ≤25W |
| Work temperature | -10℃--＋55℃ |
| Work humidity | 10％--90％ |
| Size(W*L*H(cm)) | 430*385*68mm |
