Details
| Operating System | Embedded LINUX |
| Display | |
| interface | 1. HDMI (MAX 1080P), 1. VGA (MAX1080P) |
| Resolution | 4K=3840x2160 |
| multi screen display | 1/4/8/9/16/32 |
| multi mode input | AHD: 32CH*5M-N 12 fps；32CH*4M-N 15 fps; 32CH*1080N |
| Hybird: 8CH*1080N (analog) + 8CH*960P(network); | |
| IP: 32CH*1080P；16CH*3M；8CH*5M； | |
| OSD | camera title, time, video loss, camera lock, motion detection, recording |
| Motion detection and alarm | |
| Trigger Events | Recording, PTZ, Tour, Alarm out, Video Push, Email, FTP, Buzzer |
| Motion Detection | MD Zones: 192 (16x12), Video Loss & Camera Blank |
| Alarm Input | 8 |
| Alarm Output | 1 |
| Intelligent | Perimeter Alert/ Iteams Care/ Video Diagnosis |
| Face detection | When your camera also face recognition |
| Abnormality | Event Type(No Storage, Storage Device Error, Storage No Space, Net Disconnection, IP Conflict) |
| Human Detect | Algorithm Selectable Channels |
| Alarm Input | IPC Alarm |
| Playback & Backup | |
| Playback | 1/4/8/9/16 channels (according to selected mode) |
| Search Mode | Time/Date, Alarm, MD & Exact search (accurate to second) |
| Playback Mode | Common playback/ Sync playback/ Dayparting/ Smart Express/ Smart Search/ Face Search |
| Playback Function | Play, Pause, Stop, Rewind, Common playback, intelligent fast playback, intelligent retrieval, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom |
| Backup Mode | USB Device/Network |
| Network | |
| Interface | 1 RJ-45 ports (1/10/100/1000 Mbps) |
| Ethernet Port | 1 independent 1/10/100/1000 Mbps Ethernet port |
| Network Function | DHCP, FTP, DNS, DDNS, NTP, UPNP, EMAIL,, Alarm Server, IP Search(Support Dahua IP camera, DVR, NVS etc.) |
| wireless | 3G, WI-FI |
| Max. User Access | 60 users |
| Smart Phone App | "XMEYE" on both platforms (iOS, Android) |
| Computer System Support | Windows 2000, XP, Vista, 7, 8 / Mac OS x 10.6/10.7 |
| CMS Program | XMEYE |
| Free DDNS (P2P) | P2P Function via iCloud server (http://www.xmeye.net) |
| Storage | |
| Internal HDD | 2 SATA II ports (each port support 8TB) |
| HDD Mode | read / write, read only, redundant |
| Auxiliary Interface | |
| USB | 2 x USB 2.0 ports |
| RS485 | 1 port, support all kind of PTZ protocal |
| Video& Audio | |
| Camera Input | 32 channel |
| Two-way Talk | 16 channel Input, 1 channel Output, RCA, full Duplex enabled |
| Audio compression | G.711A |
| Recording | |
| Video compression | H.265+/H.265/H.265X |
| Resolution | 5M-N, 4M-N, 3MP, 1080N, 1.3 MP, 720P etc. |
| Record Rate | 384 Mbps |
| Bit Rate | 16 kbit/s to 40 Mbit/s |
| SnapShot Conf | Cycle capture/ Timing capture |
| Record Mode | Manual, Schedule, (Regular,Continuous), MD(Video detection: Alarm detection, Video loss), Alarm, Stop |
| Record Interval | 1 to 120 min (default: 60 min), Pre-record: 1 to 30 sec, Post-record: 10 to 300 sec |
| General | |
| Power Supply | DC12V |
| Power Consumption | <15 W (Without HDD) |
| WorkingEnvironment | temperature: 0°C to +55°C; Humidity: 10% to 90%RH; pressure 86 to 106 kpa |
| Dimension(W×D×H) | 465 mm x 335 mm x 115 mm (Tolerance ±30 mm) |
| Weight | Around 4.00 kg (8.92 lbs) without HDD |
| Certification | CE, FCC, UL |
