Details
Features：
- Mobile monitor: Support all kinds of mobile monitor（iPhone, Windows Mobile, BlackBerry, Symbian, Android）
- Display：Support TV、VGA output synchronously, VGA make the traditional monitor display effect upside down
- Others：Completed protective circuit, unique treble watchdog function, make device never crashed; special “black-box” technology to monitor the device process, greatly reduce the maintenance cost.
| System | Compression Format | H.264 |
| OS | Embedded Linux | |
| Video | Input | 4CH BNC Inputs |
| Output | 2*BNC Mainout,1*VGA | |
| Audio | Audio Input | 1CH |
| Audio Output | 1CH | |
| Recording | Resolution | NTSC:D1(704×576),HD1(704×288),CIF(352×288) PAL:D1((704×480),HD1(704×240),CIF(352×240) |
| Recording | 4CH D1 real-time | |
| Recording Mode | Schedule, Manual, Motion, Sensor | |
| Playback | Playback Channel | 1/4CH |
| Decode capacity | 4CH D1 | |
| Search Mode | Time,Event list | |
| Backup | USB Disk | USB 2.0 USB flash disk ,USB hard disk, USB CD/DVD-RW burner |
| Remote Application | Browser | IE、Chrome、Firefox、Safari |
| CMS | YES | |
| User Access | Multiusers online with professional authority management | |
| Alarm | Alarm Input | NO |
| Alarm Output | NO | |
| Storage | HDD | 1*SATA HDDs,up to 2TB for each |
| PTZ | PTZ | 1*RS485 port, support multi protocol |
| PTZ Control | pan,tilt,zoom,preset,cruise, trace | |
| Network | Ethernet | 10 / 100 Mbps Ethernet (RJ-45) |
| Protocol | TCP/IP, DHCP, DDNS, NTP, SMTP | |
| Mobile phone | Support Windows OS,Symbian OS,iPhone ,Blackberry and Android operation system Mobile phone | |
| Others | Remote Control | included |
| HDMI Interfacee | included | |
| Operating Temperature | -10°C to +55°C | |
| Power supply | 12V/2.5A | |
| Spot Output | NO | |
| Humidity | 10% to 90% Humidity | |
| Dimension | L x W x H(DVR) | L250*W205*H45 |
