Details
| Image Sensor | |||
| Image Sensor | 1/2” CMOS | ||
| Effective Pixels | 2560(H)x1960(V) | ||
| Scanning System | Progressive | ||
| Electronic Shutter Speed | Auto/ manual (1/25 to 1/10000) | ||
| Minimum Illumination | 0.05 Lux@F1.2 (color) | ||
| 0.01 Lux@F1.2 (black and white ) | |||
| S/N Ratio | ≥50db(AGC OFF) | ||
| IR Distance | Distance up to 30 Meters | ||
| IR On/Off Control | Auto/ Manual | ||
| IR LEDs | 4 High Power Array LEDs | ||
| Lens | |||
| Lens Type | Fixed | ||
| Mount Type | Board-in | ||
| Focal Length | 3.6mm (2.8, 6, 8, 12 mm optional) | ||
| Max. Aperture | F1.2 | ||
| Optical Zoom | N/A | ||
| Focus Control | Fixed | ||
| Available lens | Lens | Angle (FOV) | Distance |
| 2.8 mm | 90 | 3 M | |
| Selected lens (by default) | 3.6 mm | 70 | 8 M |
| 6.0 mm | 50 | 15 M | |
| 8.0 mm | 33 | 20 M | |
| 12.0 mm | 22 | 40 M | |
| PTZ | |||
| Pan/Tilt/Zoom | N/A | ||
| Pan/Tilt/Zoom Range | N/A | ||
| Auto Zoom | N/A | ||
| Auto Track | N/A | ||
| Intelligence | |||
| IVS | N/A | ||
| Advanced Intelligent Functions | N/A | ||
| Video | |||
| Compression | H.265/H.264 | ||
| Streaming Capability | 3 Streams | ||
| Resolution | 5M (2560x1960) /3M(2304×1296)/ | ||
| 1080P(1920×1080) | |||
| 720P(1280×720) /D1(704×576/704×480) | |||
| Frame Rate | Main Stream: 5MP,3MP, 2MP all @ (1 ~ 25fps)/ | ||
| Sub Stream: D1@(1 ~ 25fps)/ | |||
| Third Stream: 720P@(1 ~ 25fps) | |||
| Bit Rate Control | CBR/VBR | ||
| Bit Rate | maximum bitrate | minimum bitrate | ultra minimum bit rate |
| 5MP: 10240bitrate @ 25fps | 2048 bitrate @25fps | D1: 95 bitrate @1fps | |
| 3MP: 10240bitrate @ 25fps | 1536 bitrate @25fps | ||
| 2MP: 8192bitrate @25fps | 1024 bitrate @25fps | ||
| Day/Night | Auto(ICR); Color; B/W | ||
| BLC Mode | Off / On | ||
| White Balance | Auto | ||
| Auto Gain Control | Auto/Manual (level 1 to 100) | ||
| Noise Reduction | 2D/3D DNR | ||
| Privacy Mask | Support 4 area privacy mask | ||
| Motion Detetion | Off / On (22x18 Zones, Rectangle) | ||
| DWDR | Auto/Manual 1/100 | ||
| Defog | Auto/Manual 1/100 | ||
| Auto Iris | Off/On | ||
| Exposure mode | Auto/Manual 1/50 to 1/10000 | ||
| Digital Zoom | Manual | ||
| Flip | Off / On | ||
| Mirror | Off / On | ||
| anti flicker | Off / On | ||
| IRSwap | Off / On | ||
| Privacy Masking | Off / On (4 Area, Rectangle) | ||
| Audio | |||
| Compression | G.711a | ||
| Network | |||
| Ethernet | RJ-45 (10/100Base-T) | ||
| Protocol | HTTP; TCP/IP; RTSP; UPNP; NTP; DAS; | ||
| FTP; DHCP; DNS; DDNS; PPPOE; IPv4/v6 | |||
| CLOUD,MOBILE PORT,EMAIL, ARSP,WIRELESS | |||
| Transmit | P2P(plug and play), automatic port forwarding | ||
| Signal Frequency | 2.4 GHz | ||
| Max. User Access | 60 Users | ||
| Edge Storage | NAS | ||
| Local PC for instant recording | |||
| Web Viewer | IE (recommended) , Chrome, Firefox, Safari, opera | ||
| Management Software | General_CMS_V3.1.0.0.T.20140717 | ||
| Smart Phone | IOS, Android (XMEYE) | ||
| Certifications | |||
| CE, UL, FCC | |||
| Interface | |||
| Video Interface | 1Vp-p composite output (75 Ω/BNC) (-S model) | ||
| Audio Interface | 1 Input | ||
| Communication Interface: | 1 RJ45 10M/100M Ethernet port | ||
| Alarm | E-mail, Client software | ||
| RS-485 (Optional) | |||
| Alarm In/Out | Optional 2/1 | ||
| System Compatibility | ONVIF V.2.4 (Profile S, Profile G) | ||
| Electrical | |||
| Power Supply | DC 12V, PoE (802.3af)(Class 0) | ||
| Power Consumption | <11W | ||
| Environmental | |||
| Operating Conditions | -20℃～+50℃ (-4F ~ +122F)，Less than 95%RH (No condensation） | ||
| Strorage Conditions | -20℃～+50℃ (-4F ~ +122F)，Less than 95%RH (No condensation） | ||
| Ingress Protection | IP66 | ||
| Construction | |||
| Casing | Metal | ||
| Dimensions (Packed) | 215 mm x 120mm x 120 mm (Tolerance +/- 20mm) | ||
| Net Weight (Packed) | 0.632kg (Tolerance +/- 0.20 kgs) | ||
