| Sensor | 1/2.8" 2.0 Megapixel CMOS AHD |
| Electronic Shutter | 1/50(1/60)~1/100000sec |
| Synchronization | Internal |
| Signal Mode | PAL/NTSC |
| Effective Pixel | 1920(H)×1080(V) |
| Noise Reduction | 2D/3D |
| Min. Illumination | 0.02LUX/F1.2(AGC ON), 0Lux IR on |
| Lens | 3.6 mm |
| IR Range | 5 to 7 meter |
| Video Standard | Comply with HD-AHD |
| Video Frame Rate | 1920×1080@25 fps;1920×1080@30 fps |
| Video Output | 1-channel BNC HD-AHD video output |
| Day/Night | Auto(ICR)/Color/Black |
| Max. Transfer distance | Normal 75-3 coaxial cable up to 500m |
| Weather Proof Standard | IP65 |
| Working Temperature | -20℃~+50℃,Less than 95%RH (No condensation) |
| Power | DC12V±10﹪ |
