Image Sensor | |||
Sensor size | 1/2.5” | ||
Effective Pixels | 3027(H)x1728(V) | ||
TV System | PAL/NTSC | ||
Scanning System | Progressive | ||
S/N Ratio | ≥58db | ||
IR Distance | 20 m | ||
IR On/Off Control | Auto/ Manual | ||
IR LEDs | 2 High Power Array LEDs | ||
Lens | |||
Lens Type | Fixed | ||
Mount Type | Board-in | ||
Focal Length | (2.8, 3.6, 6, 8, 12 mm fixed) | ||
Max. Aperture | F1.2 | ||
Optical Zoom | N/A | ||
Focus Control | Fixed | ||
Available lens | Lens | Angle (FOV) | Distance |
Selected lens (by default) | 2.8 mm | 90 | 3 M |
3.6 mm | 70 | 8 M | |
6.0 mm | 50 | 15 M | |
PTZ | |||
Pan/Tilt/Zoom | N/A | ||
Pan/Tilt/Zoom Range | N/A | ||
Auto Zoom | N/A | ||
Auto Track | N/A | ||
Intelligence | |||
IVS | N/A | ||
Advanced Intelligent Functions | N/A | ||
Video | |||
Video Output | AHD, TVI, CVI, CVBS | ||
Streaming Capability | 2 Streams | ||
Resolution | 5MP(20fps/12.5fps)/4MP(30/25/15)fps/1080P(30/25)fps | ||
720P/960H/D1 | |||
Frame Rate | Main Stream: 5MP@(1 ~ 20fps) | ||
Sub Stream: D1@(1 ~ 25fps); | |||
Bit Rate Control | CBR/VBR | ||
Bit Rate | maximum bitrate | minimum bitrate | ultra minimum bit rate |
5MP: 3948bps @ 13fps | 5MP: 789bps @ 13fps | D1: 34bps @1fps | |
Day/Night | Auto(ICR); Color; B/W, | ||
Brightness | 1 to 20 | ||
White Balance | ATW/MWB | ||
Exposure Mode | Globe/BLC/FLC | ||
Contrast | 1 To 16 | ||
Sharpness | 1 To 16 | ||
Color Gain | 1 To 16 | ||
DNR | 1 To 16 | ||
D-WDR | Off / On | ||
Smart IR | N/A | ||
Mirror | H/V/HV/Default | ||
Digital Zoom | Manual | ||
Interface | |||
Video Interface | BNC | ||
OSD | Available | ||
UTC | Available | ||
White Balance | ATW | ||
Electrical | |||
Power Supply | DC 12V | ||
Power Consumption | <11W | ||
Environmental | |||
Operating Conditions | -10℃~+50℃ (-4F ~ +122F),Less than 95%RH (No condensation) | ||
Strorage Conditions | -20℃~+50℃ (-4F ~ +122F),Less than 95%RH (No condensation) | ||
Ingress Protection | IP65 Standard | ||
Construction | |||
Casing | Plastic | ||
Dimensions (Packed) | 132 mm x 132 mm x 115 mm (Tolerance +/- 20mm) | ||
Net Weight (Packed) | 0.25 kg (Tolerance +/- 0.15 kgs) |
