Details
| Image Sensor | |||
| Image Sensor | 1/3” CMOS | ||
| Effective Pixels | 1920(H) x 1080(V) | ||
| Scanning System | Progressive | ||
| Electronic Shutter Speed | auto/ manual (1/2 to 1/20000) | ||
| Minimum Illumination | 0.1 Lux@F1.2 (color) | ||
| 0.01 Lux@F1.2 (black and white ) | |||
| S/N Ratio | ≥50db(AGC OFF) | ||
| IR Distance | Distance up to 150m | ||
| IR On/Off Control | Auto /Manual | ||
| IR LEDs | 8Pcs Array 42Mil | ||
| Lens | |||
| Focal Length range | 4.7mm -95mm | ||
| Aperture Range | F1.6~F2.8 | ||
| Zoom Speed | Turbo | ||
| FOV | 4.2°-68.5° | ||
| Mount Type | Board-in | ||
| Optical Zoom | 20 X | ||
| Focus Control | Auto /Manual | ||
| PTZ | |||
| Pan/Tilt/Zoom | Auto /Manual | ||
| Pan Range | 360° conttinuous rotation | ||
| Tilt Range | 0°~93° auto flip 180° | ||
| Pan Speed | speed: 0-200°/s | ||
| Tilt Speed | speed: 0-100°/s | ||
| Zoom Range | 20x | ||
| Preset Points | 220 | ||
| Guard Tours | 3 groups | ||
| A-B Scan | User programmable | ||
| A-B Scan Speed | 1-64 levels setting available | ||
| Dwell Time | 01-60s interval available | ||
| PWR On Action | Memory/Tour 1/360° scan/A-B scan/Preset 1-8/None | ||
| Park Time | 1-60mins available | ||
| Communication Protocol | ONVIF2.4 ,Compatible with DAHUA, XM,Video park NVR | ||
| Baud Rate | 9600bps by default | ||
| Guard Points | Max.16 points, dwell time user selectable | ||
| Operation menu | English | ||
| Pan Position Display | Support | ||
| Auto Control IR LED | PWM | ||
| Pan and Tilt Position Display | Support | ||
| Support Ambient Light Detection | IR illumination on 1-9 grades selectable; | ||
| Intelligence | |||
| IVS | N/A | ||
| Advanced Intelligent Functions | N/A | ||
| Video | |||
| Compression | H.265+ /H.265 /H.264+/H.264 | ||
| Streaming Capability | 3 Streams | ||
| Resolution | 1080P(1920×1080)/1.3M(1280x960)/ | ||
| 720P(1280×720)/D1(704×576/704×480)/ | |||
| VGA(640×480)/CIF(352×288/352×240) | |||
| Frame Rate | Main Stream: 2MP@(1 ~ 30fps) | ||
| Sub Stream: D1@(1 ~ 30fps); | |||
| Third Stream: 720P@(1 ~ 30fps) | |||
| Bit Rate Control | CBR/VBR | ||
| Bit Rate | maximum bitrate | ||
| 2MP: 5000bitrate @30 fps | |||
| Day/Night | Auto(ICR); Color; B/W | ||
| BLC Mode | Off / On | ||
| White Balance | Auto /Manual (Red gain /Blue gain) | ||
| Auto Gain Control | Auto/Manual (level 1 to 100) | ||
| Noise Reduction | 3D DNR | ||
| Privacy Mask | Support 4 area privacy mask | ||
| Motion Detetion | Off / On (22x18 Zones, Rectangle) | ||
| Region of Interest | N/A | ||
| Electronic Image Stabilization (EIS) | N/A | ||
| Smart IR | Support | ||
| Defog | Off / On (level 1 to 100) | ||
| Digital Zoom | Manual | ||
| Flip | Off / On | ||
| Mirror | Off / On | ||
| anti flicker | Off / On | ||
| IRSwap | Off / On | ||
| Privacy Masking | Off / On (4 Area, Rectangle) | ||
| Audio | |||
| Audio | N/A | ||
| Network | |||
| Ethernet | RJ-45 (10/100Base-T) | ||
| Protocol | TCP/IP，HTTP， NTP，IGMP | ||
| DHCP，UDP，SMTP，RTP，RTSP，ARP，DDNS，DNS，PPPoE，P2P | |||
| Transmit | P2P(plug and play), automatic port forwarding | ||
| Signal Frequency | 2.4 GHz | ||
| Max. User Access | 7 Users | ||
| Edge Storage | NAS | ||
| Local PC for instant recording | |||
| Web Viewer | IE(recommended), Chrome, Firefox, Safari, opera | ||
| Management Software | General_CMS_V3.1.0.0.T.20140717 | ||
| Smart Phone | IOS, Android (XMEYE) | ||
| Certifications | |||
| CE, UL, FCC | |||
| Interface | |||
| Audio Interface | N/A | ||
| Communication Interface: | 1 RJ45 10M/100M Ethernet port | ||
| Alarm | N/A | ||
| System Compatibility | ONVIF V.2.4 (Profile S, Profile G) | ||
| Electrical | |||
| Power Supply | DC 12V (4A) / PoE | ||
| Power Consumption | <11W | ||
| Environmental | |||
| Operating Conditions | -10℃～+50℃ (-4F ~ +122F)，Less than 95%RH (No condensation） | ||
| Strorage Conditions | -20℃～+50℃ (-4F ~ +122F)，Less than 95%RH (No condensation） | ||
| Ingress Protection | IP66 Standard | ||
| Construction | |||
| Casing | Metal and Plastic | ||
| Dimensions (Packed) | 640x465x330mm | ||
| Net Weight (Packed) | 6kg (Tolerance +/- 0.20 kgs) | ||
